Keysight (Agilent/HP) 8510B
Frequency range 45 MHz to 40 GHz (depending on the connected test set), Real-time measurements with error correction, 60 dB effective directivity, 40 dB source match, Dynamic range 80 to 100 dB, Measurement resolution of 0.001 dB, 0.01 degrees and 0.01 ns, Time-domain analysis, HP-IB interface. The synthesizer sweep generators of the HP 8350 A/B, 8340A/B, 836XX series, etc. are particularly suitable as RF sources. NETWORK ANALYZER 45 MHz - 40 GHz
Product variants:
-
Keysight (Agilent/HP) 8510B
