LeCroy LC534AL
4 channels, frequency range from DC to 1 GHz, 500 MS/s, 2 Mpts/channel, maximum sampling rate 4 ms (single-shot), sensitivity 2 mV/div to 1 V/div (50 ohm), typical accuracy 1%, vertical resolution 8 bit, maximum input voltage 400 V (1 MOhm), timebase 1 ns/div to 1000 s/div, interpolator resolution 10 ps, auto setup, internal memory 16 MByte, horizontal zoom factor 100,000x, 3.5" FDD, GPIB interface, display on 9" color raster scan CRT with 0.26 mm dot pitch. DIGITAL OSCILLOSCOPE 1 GHz, 500 MS/s, 4 channels
Product variants:
-
LeCroy LC534AL
