Kikusui TOS8850A
For measurements on insulation according to recommendations in line with JIS, UL, CSA, CEE, BS and VDE, test voltages from 0 to 2.5 kV and 0 to 5 kV, maximum source output 500 VA, leakage current measurement 0.5 mA to 100 mA in 7 ranges, insulation resistance 1 to 1000 MOhm and 2 to 2000 MOhm. Adjustable window comparators for rapid evaluation whether required values are met (Go/No-Go test). Optional audible status indication. Ideal also for measurements on production lines. INSULATION TESTER 0 - 2.5 kV / 5 kV
Product variants:
-
Kikusui TOS8850A
