Anritsu MT8801C
Wireless phones for nearly every wireless telephone system in the world can be tested using just one MT8801C Radio Communication Analyzer. These systems include IS-95 and CDMA2000 1X (all 10 band classes), AMPS, GSM, GPRS, HSCSD, IS-136, PDC, and PHS with the appropriate measurement software options. The frequency range covered is 300 kHz to 3 GHz. The optional spectrum analyzer function covers 10 MHz to 3 GHz and is very useful for measuring spurious signals near the carrier as well as for general-purpose troubleshooting. GP-IB and RS-232C interfaces are standard, permitting incorporation in automated test systems. External Computer-aided Radio Communication Analysis (CRCA) software simplifies repeatable test sequences by external control of the tester over GP-IB. Options 01 Analog Measurement 04 AF Low Impedance Output Requires Option 01 07 Spectrum Analyzer 11 GSM Audio Test Requires MX880115A and Option 01 12 CDMA Measurement Requires Option 01 FUNKMESSPLATZ 300 kHz - 3 GHz
Product variants:
-
Anritsu MT8801C -
Anritsu MT8801C
